Author
|
Topic: Oil pressure sending unit??
|
|
|
SLOW95GTS
¯
Member # 10365
|
posted


someone probably just put the bigger one on your car, but the one in link should fit no problem.
[ 2014-05-14, 01:18 PM: Message edited by: SLOW95GTS ]
--------------------
1995 Mustang GTS 5.0 - "minor mods"
Posts: 1199 | From: East Bay | Registered: Oct 2010
| :
|
|
|
|
SLOW95GTS
¯
Member # 10365
|
posted
yeah didn't see that you had a 93, but the threads are basically the same for all 302, and 351's. I have put a 95 sending unit on a old 69' 351w block . I had the fatter one on my 86 and it failed on me. So, the newer is most likely a better design w/ less failure.
--------------------
1995 Mustang GTS 5.0 - "minor mods"
Posts: 1199 | From: East Bay | Registered: Oct 2010
| :
|
|
30Tunes
¯
Member # 8105
|
posted
Right on for the feedback. I have that long extension where the sending unit plugs into, can/should I eliminate that now that ill be using the smaller one?
--------------------
SUCCESS ONLY COMES BEFORE WORK IN THE DICTIONARY
1991 Calypso Green Notch
1993 Cobra Clone - SOLD
Posts: 829 | From: Bay Area | Registered: Dec 2007
| :
|
|
SLOW95GTS
¯
Member # 10365
|
posted
yup, since its gonna fit now haha. the 79-89 used that extension.
--------------------
1995 Mustang GTS 5.0 - "minor mods"
Posts: 1199 | From: East Bay | Registered: Oct 2010
| :
|
|
Marks93
¯
Member # 11130
|
posted
Do you have an aftermarket gauge? Autometer has the fatter sending unit which requires the extension. Otherwise it hits the block and won't screw in.
If you are using the stock gauge in the gauge cluster, the smaller one is the right one.
Posts: 824 | From: Earth | Registered: Jul 2011
| :
|
|
30Tunes
¯
Member # 8105
|
posted
I do have the aftermarket gauge, I don't have it hooked up though. I'll buy the one that recommended for my year and eventually hook up my aftermarket gauge and buy the other one too. Thanks for everyones help!
--------------------
SUCCESS ONLY COMES BEFORE WORK IN THE DICTIONARY
1991 Calypso Green Notch
1993 Cobra Clone - SOLD
Posts: 829 | From: Bay Area | Registered: Dec 2007
| :
|
|
Tom Renzo
¯
Member # 13165
|
posted
The big one is for a gauge the smaller one is for a light!! That is what it looks like to me!!
--------------------
I spend money i don't have. Building cars i don't need. To impress people i don't know.
Posts: 557 | From: CT | Registered: Sep 2013
| :
|
|
NK2186
¯
Member # 12319
|
posted
my 89 had the bigger one with the extension on it.
When i replaced the motor i built it with a 95 block and heads. The same unit screwed in without an issue.
if you already have the one with the extension just rock the bigger unit. they both electronically work the same from what i remember.
--------------------
90 LX 5.0 - Stolen/stripped
89 LX 5.0 - Stolen and missing as of 7-24-13. LIC# 4HIP151 :(
99 Cobra
00 Exploder
Posts: 400 | From: Haystack | Registered: Aug 2012
| :
|
|
30Tunes
¯
Member # 8105
|
posted
Replaced it with the one that my year called for and the level is 3/4 the way up but I don't see it fluctuating when I get on the gas. Usually the pressure would build when on the gas?? Think its fine?
--------------------
SUCCESS ONLY COMES BEFORE WORK IN THE DICTIONARY
1991 Calypso Green Notch
1993 Cobra Clone - SOLD
Posts: 829 | From: Bay Area | Registered: Dec 2007
| :
|
|
KevinK
Tech Mod
Member # 9234
|
posted
Not sure why the change but the Ford parts book shows 79-88 for the old style e4zz part number which also dates back to the late 60s cars. In 89 the sending unit changed for the 5.0. The 2.3 is different.
Posts: 202 | From: San Mateo, CA | Registered: Jun 2009
| :
|
|
